Here are the most important 4 common symptoms of steering angle sensor failure and its testing. Steering angle sensor (SAS) is a critical component in a vehicle’s electronic stability control system. Its primary function is to monitor the position and angle of the steering wheel and provide this information to various systems within the vehicle. Here’s a breakdown of its function, common failure symptoms, and testing procedures.

The steering angle sensor is a critical component within a vehicle’s electronic stability control system, responsible for measuring and transmitting the angle of the steering wheel to the electronic control unit (ECU). This information is vital for the proper operation of safety and stability systems, including traction control and electronic stability control.

When the steering angle sensor experiences issues, discernible symptoms emerge, such as inconsistent or inaccurate readings on the vehicle display, activation of stability control warning lights, and potential disturbances in the functionality of safety features like traction control.

To identify potential problems with the steering angle sensor, diagnostic methods come into play. Utilizing a diagnostic scanner allows for the retrieval of error codes from the vehicle’s ECU. Additionally, a thorough visual inspection of the sensor and its wiring is essential to detect any signs of damage or corrosion. In certain cases, dynamic calibration procedures may be necessary. This involves real-time observation of the sensor’s readings while the vehicle is in motion to pinpoint irregularities and ensure accurate functionality.

Function:

  1. Stability Control: The SAS is a vital part of the vehicle’s electronic stability control system. It constantly measures and reports the angle and position of the steering wheel to the vehicle’s onboard computer.
  2. Yaw Rate and Lateral Acceleration Sensors: The SAS data is used in conjunction with information from the yaw rate sensor and lateral acceleration sensor to determine the vehicle’s actual direction and movement. This helps the vehicle’s stability control system respond appropriately to sudden changes in steering or unexpected road conditions.
  3. Traction Control: SAS data also assists in traction control by helping the vehicle determine whether there is understeer (front wheels losing grip) or oversteer (rear wheels losing grip), allowing the traction control system to make adjustments.

Failure Symptoms:

  1. Stability Control Warning Light: A malfunction in the SAS is often indicated by the illumination of the stability control warning light on the dashboard.
  2. Loss of Traction Control: A failed SAS can lead to a loss of stability and traction control functionality, which can be particularly noticeable during hard cornering or slippery road conditions.
  3. Unexpected ABS Activation: If the SAS isn’t providing accurate data to the stability control system, the anti-lock braking system (ABS) may engage unexpectedly during normal driving, causing the brake pedal to pulsate.
  4. Incorrect Steering Assist: Some vehicles may use SAS data for electric power steering systems, and a failure can lead to changes in steering effort or feel.

Testing:

If you suspect an issue with the steering angle sensor, you can perform the following tests:

  1. Scan Tool Diagnosis: Most modern vehicles have onboard diagnostics that can read fault codes. Using a scan tool, you can check for any diagnostic trouble codes (DTCs) related to the SAS. If there’s a code, it will help pinpoint the issue.
  2. Visual Inspection: Visually inspect the wiring harness and connectors associated with the SAS for damage, corrosion, or loose connections. Ensure that the sensor itself is securely attached to the steering column.
  3. Recalibration: Some vehicles allow for recalibrating the SAS by turning the steering wheel to specific angles and following a prescribed procedure outlined in the service manual. This can sometimes resolve minor sensor alignment issues.
  4. Resistance Testing: You can measure the resistance of the SAS using a multimeter to check for any open circuits or shorts. Consult the vehicle’s service manual for the appropriate resistance values.
  5. Replacement: If the SAS is determined to be faulty, it may need to be replaced. This should ideally be done by a trained mechanic or technician who can calibrate the new sensor correctly.

It’s important to address any issues with the steering angle sensor promptly since it’s an integral part of the vehicle’s safety and stability control systems. If you’re not experienced in automotive diagnostics, it’s recommended to consult a qualified mechanic or technician for proper testing and repair.

Related products

1. What Are the 4 common symptoms of steering angle sensor failure and Its testing?

If you’re experiencing steering angle sensor failure, there are 4 common symptoms to watch for. These include:

  1. Illuminated Warning Lights – A “steering” or “ESP” light may appear on the dashboard.
  2. Unresponsive Steering – Your vehicle may not respond correctly to steering input, making it harder to control.
  3. Poor Handling – The vehicle may pull to one side or feel unstable while driving.
  4. Cruise Control Malfunction – Cruise control may fail to work or behave erratically. Identifying these symptoms early can help prevent further damage.
2. How Do I Test the Steering Angle Sensor for Failure?

Testing the steering angle sensor for failure involves using a diagnostic scanner to read error codes from the vehicle’s ECU. You can also manually check if the sensor is responding correctly to steering wheel movement. If the sensor doesn’t adjust with the wheel’s position or the reading is inconsistent, it may be faulty. For accurate testing, it’s recommended to consult a professional mechanic in the UK to avoid incorrect diagnoses.

3. Can Steering Angle Sensor Failure Affect My Vehicle’s Safety?

Yes, steering angle sensor failure can affect your vehicle’s safety. Since the sensor provides critical data for stability control and traction systems, failure can lead to erratic handling, difficulty steering, and problems with advanced safety features such as lane-keeping assist. It’s crucial to address these issues promptly to maintain the safety and performance of your vehicle, particularly on UK roads.

4. How Much Does It Cost to Replace a Steering Angle Sensor in the UK?

The cost to replace a steering angle sensor in the UK typically ranges from £150 to £400, depending on your vehicle model and whether you choose an OEM or aftermarket part. Labour costs may add an additional £50 to £100. If you suspect steering angle sensor failure, it’s advisable to get a proper diagnosis and quote from a local mechanic.

5. Can I Drive with a Faulty Steering Angle Sensor?

While you can technically drive with a faulty steering angle sensor, it’s not recommended. Ignoring the 4 common symptoms of steering angle sensor failure—such as unresponsive steering and warning lights—can lead to poor handling and reduced safety, particularly in emergency situations. It’s important to have the sensor tested and replaced to ensure your vehicle’s stability control and traction systems are functioning properly.
